Double Stage Regenerative Blower Model SPB DS-150P

Double Stage Regenerative Blower Model SPB DS-150P Specification

Flow Rate
150 m3/h

Pressure Range
Up to 190 mbar

Life Span
Long Life

Motor Power
2 HP

Power
1.5 kW

Vaccum Range
Up to -140 mbar

Max Pressure
190 mbar

Output Power
1.5 kW

Product Type
Double Stage Regenerative Blower

Material
Aluminium Alloy

Capacity
150 m3/h

Pressure
190 mbar

Application
Pneumatic conveying, Air supply, Vacuum and pressure applications, Printing, Packaging

Frequency (MHz)
50 Hz

Motor Speed
2850 RPM

Noise Level
72 dB(A)

Power Source
Electric

Voltage
220V / 380V

Weight
24 kg

Dimension (L*W*H)
450 mm x 370 mm x 410 mm

Color
Grey

Mounting Type
Foot mounted

Cooling Type
Air cooled

Impeller Type
Aluminium Die cast

Protection Class
IP54

Inlet/Outlet Diameter
1.5 inch (38 mm)

Insulation Class
F

Double Stage Regenerative Blower Model SPB DS-150P Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Supply Ability
50 Units Per Month

Delivery Time
10 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

About Double Stage Regenerative Blower Model SPB DS-150P

Introducing the magnificent Double Stage Regenerative Blower Model SPB DS-150P-a paragon of advanced engineering for pneumatic conveying, air supply, and vacuum applications. With an inlet/outlet diameter of 1.5 inches and a robust foot-mounted design, this trending blower delivers a sublime performance at a best price for advance purchase. Its aluminium die-cast impeller, F-class insulation, and IP54 protection ensure long-lasting reliability. Operating at 220V/380V and delivering a flow rate of 150 m3/h, it is ideal for printing, packaging, and a variety of industrial applications across India.

Optimized Applications and Usage

The Double Stage Regenerative Blower Model SPB DS-150P is tailored for pneumatic conveying, vacuum, pressure applications, and air supply. Specifically designed for demanding environments, it supports usage in printing and packaging sectors. Thanks to its versatile media compatibility and electric power source, the blower accommodates continuous and intermittent usage, offering reliability for both light and heavy-duty operations, making it an optimal choice for a wide range of industrial demands.

Certifications, Packaging & Order Processing

All our SPB DS-150P blowers are delivered with certified assurance, ensuring quality and compliance. During order processing, each unit is carefully packaged for safe handover, minimizing the risk of transit damage. Customers can rely on transparent quotation procedures and flexible payment terms tailored to their procurement preferences. With dedicated distributors and service providers across India, seamless order-to-delivery transitions are guaranteed for every valued client.

FAQ's of Double Stage Regenerative Blower Model SPB DS-150P:

Q: How does the Double Stage Regenerative Blower Model SPB DS-150P benefit industrial processes?

A: This blower provides reliable, efficient air movement for pneumatic conveying, vacuum, and pressure systems, ensuring optimal performance in printing, packaging, and other demanding industrial applications.

Q: What is the process for purchasing the SPB DS-150P at the best price?

A: To secure the most competitive rate, take advantage of our advance purchase options. Request a quotation through our website or authorized distributors, and our team will assist with seamless order processing.

Q: Where can the SPB DS-150P be supplied and installed?

A: This blower is supplied and supported across India by our network of distributors, manufacturers, and service providers, with installation guidance provided upon handover.

Q: When is the SPB DS-150P recommended for use?

A: It is best used in environments requiring stable air flow and vacuum capabilities, such as pneumatic conveying, air supply systems, and industrial vacuum applications, especially in printing and packaging sectors.

Q: What certifications does the SPB DS-150P possess for industrial assurance?

A: Each unit ships with appropriate certifications ensuring quality, safety, and operational compliance, giving customers confidence in their investment and product reliability.
